Vehicle Info NeededUNITED ENGINE MACHINEPART NUMBER: 648-IC744.060
ICON Premium Forged Small Block Chrysler 360 ci Piston Set 4.060 in. Bore
$68484
Ships Tomorrow
Lowest Price GuaranteeChrysler 408ciFlat Top Pistons Use w/6.123" Connecting Rods
- Small Block Chrysler 360 ci Forged Pistons
- Flat Top 2V
- 4.060 in. Bore (+.060 in.)
- 6.123 in. Connecting Rod
- 4.000 in. Crank Stroke
- 5cc Head Volume
- Comp. Ratio: 12.4/60 cc; 11.5/65 cc; 11.0/70 cc
- Set of 8
Technical Specs: - Alloy: Premium High Ductility 2618
- Bore: 4.060"
- Crankshaft Stroke: 4.000"
- Connecting Rod Length: 6.123"
- Deck Height: 9.599'
- Compression Height: 1.465'
- Pin Size: 0.9842' x 2.750"
- Pin Location: Centered
- Flat Top: 2 Valve Reliefs
- Effective Head Volume: 5cc
- Intake Valve Relief: 0.243' Depth / 2.200' Diameter
- Exhaust Valve Relief: 0.232' Depth / 1.720' Diameter
- Top Landing Height: 0.222'
- Ring Grooves: 1/16' Top; 1/16' Middle; 3/16' Bottom
- Gram Weight: 507/118
- Compression Ratio: 12.4:1 w/60cc Heads; 11.5:1 w/65cc Heads; 11.0 w/70cc
United Engine and Machine Company is proud to introduce our new Icon line of forged pistons. Icon brings the same quality and performance you've come to expect from other United Engine brands while adding a new lightweight forged design. No matter your high performance application, there is an Icon piston for you.
Features:
- High ductility 2618 alloy
- Perfect for Nitrous, Turbocharged and Supercharged Apps
- Dual forced pin oiling on most applications
- Lateral gas porting on higher compression ratios
Show More
- Fully machined with deep valve pockets
- Second land accumulator grooves
- Top land mini groove technology
- Diamond finished skirts
- Triple wound spiral locks
- Spacer rings included in short compression heights that intersect the wrist pin bore
- Sold in Sets (except when noted as 1 piston per package)
Part TypePiston
Product LineUEM Pistons Icon Premium Forged Series Small Block Chrysler Pistons
BrandUNITED ENGINE MACHINE
Package Height4.9
Package Width9.5
Package Length18.9
Weight12.68 PG
Part CategoryPerformance Parts
Part FitmentSemi Universal
Vendor Part NumberIC744.060
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
