Ford 289 / 302 / 393ciFlat Top Pistons
- Ford 289/302/393ci FHR Forged Piston
- Flat Top 4V
- 4.000'' Bore
- 289ci use w/5.155'' Connecting Rod & 2.870'' Stroke
- 302ci use w/5.090'' Connecting Rod & 3.000'' Stroke
- 393ci use w/5.956'' Connecting Rod & 3.850'' Stroke
- 1/pkg
This piston is based and intended for use on the Windsor-based Small Block Ford.
Technical Specs: - Alloy: Premium 4032 Alloy
- Bore: 4.000'
- Crankshaft Stroke: 2.870'(289ci); 3.000'(302ci); 3.850'(393ci)
- Connecting Rod Length: 5.155'(289ci); 5.090'(302ci); 5.956'(393ci)
- Deck Height: 8.206'(289/302ci); 9.500'(393ci - 351W Block)
- Compression Height: 1.608' (all)
- Pin Size: 0.912' x 2.750'
- Pin Location: Offset
- Flat Top: -11cc 4 Symmetrical Valve Reliefs
- Intake Valve Relief: N/A
- Exhaust Valve Relief: N/A
- Top Landing Height: 0.247'
- Ring Grooves: 5/64' Top; 5/64' Middle; 3/16' Bottom
- Gram Weight: 528/131
- Compression Ratio (289ci): 9.2:1 w/54cc Heads; 8.8:1 w/58cc Heads; 8.2:1 w/64cc
- Compression Ratio (302ci): 9.5:1 w/54cc Heads; 9.1:1 w/58cc Heads; 8.5:1 w/64cc
- Compression Ratio (393ci): 12.0:1 w/54cc Heads; 11.4:1 w/58cc Heads; 11.0:1 w/64cc
BrandUNITED ENGINE MACHINE
Part CategoryPerformance Parts
Vendor Part NumberSIC9924.STD
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
