Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Pontiac 400ciFlat Top Pistons
- Pontiac 400ci FHR Forged Piston
- Flat Top 4V
- 4.160'' Bore (+.040'')
- Use w/6.630'' Connecting Rod & 3.750'' Crank Stroke
- Comp. Ratio: 10.1/72cc; 8.8/87cc; 8.2/96cc
- 1/pkg
Note: Will work with 14-degree and 20-degree heads.
Technical Specs: - Alloy: Premium 4032 Alloy
- Bore: 4.160'
- Crankshaft Stroke: 3.750'
- Connecting Rod Length: 6.630'
- Deck Height: 10.250'
- Compression Height: 1.714'
- Pin Size: 0.980' x 3.000'
- Pin Location: Offset
- Flat Top: -10.8cc 4 Symmetrical Valve Reliefs
- Intake Valve Relief: N/A
- Exhaust Valve Relief: N/A
- Top Landing Height: 0.270'
- Ring Grooves: 5/64' Top; 5/64' Middle; 3/16' Bottom
- Gram Weight: 563/149
- Compression Ratio: 10.1:1 w/72cc Heads; 8.8:1 w/87cc Heads; 8.2:1 w/96cc
Part TypePiston
BrandUNITED ENGINE MACHINE
Part CategoryPerformance Parts
Part FitmentSemi Universal
Vendor Part NumberSIC9946.040
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
