Vehicle Info NeededUNITED ENGINE MACHINEPART NUMBER: 648-KB156.030
Chevy 327ci Hypereutectic Pistons Flat Top
$43363
Ships on 09/08/2026
Lowest Price GuaranteeChevy 327ciFlat Top Pistons
- Chevy 327ci Hypereutectic Pistons
- Flat Top
- 4.030'' Bore (+.030'')
- Use w/5.700'' Connecting Rod & 3.250'' Crank Stroke
- Comp. Ratio: 10.3/58cc; 9.8/62cc; 9.6/64cc; 8.4/76cc
- 8/pkg
Technical Specs: - Alloy: Hypereutectic 390
- Bore: 4.030'
- Crankshaft Stroke: 3.250'
- Connecting Rod Length: 5.700'
- Deck Height: 9.025'
- Compression Height: 1.678'
- Pin Size: 0.9272'
- Pin Location: Centered
- Flat Top: -7cc 2 Symmetrical Valve Reliefs
- Intake Valve Relief: 0.280' Depth / 2.168' Diameter
- Exhaust Valve Relief: 0.280' Depth / 2.168' Diameter
- Top Landing Height: 0.275'
- Ring Grooves: 5/64' Top; 5/64' Middle; 3/16' Bottom
- Gram Weight: 569/145
- Compression Ratio: 10.3:1 w/58cc Heads; 9.8:1 w/62cc Heads; 9.6:1 w/64cc; 8.4:1 w/76cc Heads
Part TypePiston
BrandUNITED ENGINE MACHINE
Package Height4.0
Package Width9.4
Package Length18.1
Weight13.92 PG
Part CategoryPerformance Parts
Part FitmentSemi Universal
Vendor Part NumberKB156.030
Package Qty1
Package TypeEA
