Vehicle Info NeededUNITED ENGINE MACHINEPART NUMBER: 648-KB240KTM.STD
Chrysler 400ci Hypereutectic Pistons Flat Top
$67635
Ships on 09/08/2026
Lowest Price GuaranteeChrysler 400ciFlat Top Pistons
- Chrysler 400ci Hypereutectic Pistons
- Flat Top
- 4.342" Bore
- Use w/ 6.358" Connecting Rods & 3.380" Stroke
- Comp. Ratio: 10.3/72cc; 9.5/80cc; 9.2/84cc; 8.9/88cc
- 8/pkg.
Specs: - Bore: 4.342"
- Rod Length: 6.358"
- Pin Diameter: 1.0940"
- Stroke: 3.380"
- Comp. Ht: 1.908"
- Top Land: 0.275"
- OE Deck Height: 9.980"
- Weight Piston/Pin: 660/190"
- Head Type: Flat Top
- Effective Head Volume: 8cc
- Ext. Valve Depth: 0.264"
- Ext. Valve Dia.: 2.360"
- Int. Relief Depth: 0.264"
- Int. Relief Dia.: 2.360"
- Ring Packs: 2-5/64, 1-3/16
Part TypePiston
BrandUNITED ENGINE MACHINE
Package Height7.1
Package Width9.8
Package Length18.7
Weight15.57 PG
Part CategoryPerformance Parts
Part FitmentSemi Universal
Vendor Part NumberKB240KTM.STD
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
