Vehicle Info NeededV-3 Si-Trim Supercharger
Ships on Sep 08, 2026
Lowest Price Guarantee- 45 Degree Tilt to the Right
- Straight Discharge
- Satin Finish
- Max Boost 22 PSI
- Max Power: 775 HP
Features: - Max Speed: 52000 RPM
- Max Boost: 22 PSI
- Max Flow: 1150 CFM
- Max Power: 775 HP
- Peak Efficiency: 78%Dimensions:
- Discharge OD: 2.75"
- Inlet OD: 3.5"
- Discharge ID: 2.38"
- Inducer Diameter: 3.1"
Emissions Note:
This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.
CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
Each Vortech Supercharging System is developed to operate as a seamless addition to the base vehicle. By employing the same methods as original manufacturers, Vortech engineers create integrated supercharger systems that appear as if they're original equipment yet operate at an even higher level of sophistication. The boost curve generated by Vortech Superchargers is ideally matched with today's highly evolved engines and provides a power-when-you-need-it sensation. The supercharger and its subsystems fully integrate into the vehicle's existing platform, yielding a smooth continuity of power and performance.
Show More
Tuner Kits
These configurations are designed for those qualified tuners or race shops who do not require the fuel managements items included in Vortech's standard systems. Among the items excluded are fuel pump, fuel injectors, FMU, air inlet assembly (T-Trim models), and ECM programmer or timing controller.
Features:
- Gear driven, centrifugal supercharger with SQ technology provides quiet operation and unmatched reliability
- Technologically advanced, high-efficiency compressor stage design developed in Vortech's supercharger test cell
- Supercharger drive system includes all necessary belts, pulleys, idler and tensioner
- High-flow bypass valve provides surge-free compressor operation
- Fuel management/calibration components used are high-capacity fuel injectors, high-flow fuel pump, fuel management unit (FMU), high-flow MAF, ECM chip or module, ECM re-programmer and timing controller (These items vary per application. Click More Info below for details.)
- Oil feed & oil drain assemblies deliver the best possible lubrication and cooling for the supercharger, preferred for sustained boost conditions
- High-flow air intake configuration with reusable air filter and specially designed inlet ducts for superior fit
- Inlet and discharge duct connections utilize heat-resistant silicon sleeves and premium quality stainless steel clamps
- OE-type cast aluminum or billet aluminum mounting bracketry for rigidity and a factory-installed appearance
- Compatible with factory OBD-II engine management systems
