ATK Core Return Process
JEGS and ATK appreciate your business and want to ensure that your core return is as smooth as possible.

Please CLICK HERE for ATK Core Return Process

NOTE:

• Core return can be any Chevy LS 6.0L engine

Engine Info

• Exhaust: 1-5/8" Headers
• Firing Order: 18726543
• Octane: 91+
• Oil: 10W30
• Oil Filter: Wix or K&N
• Spark Plug Gap: .040"
• Stall Converter: 2500
• Timing: Set to factory specifications via PCM module (Tune Required)

Recommended Components

• Balancer: Stock internal balance/per application
• Intake Manifold: Stock EFI, aftermarket EFI, or carbureted  intake
• Flexplate/Flywheel: Stock internal balance
• Fuel Pump: Electric per application
• Fuel Injectors: 36lb injectors
• Spark Plugs: NGK #739-TR5GP
• Spark Plug Wires: Factory
• Water Pump: Per application

Notes: This engine can replace the 1999-2007 Chevy 5.3L LM7 engine with supporting modifications or any other factory LS equipped vehicle. It can also be retrofitted for an aftermarket EFI/Carb setup. ECM must be tuned, not doing so can damage the engine.

Disclaimer: Power figures can vary based on parts used by the end user. Some modifications to the vehicle may be required using these and or other aftermarket parts.

Engine Break-In Procedure

Use conventional or break-in oil (non-synthetic) for the first 600 miles of operation. Do not drive for long periods at any single speed, always vary your speed. Do not tow a trailer or put other heavy loads on the vehicle. Check the engine oil and coolant levels daily.

At 600 Miles change the engine oil and filter using conventional (non-synthetic) oil. Check fuel and ignition settings; adjust valves (where applicable).

After the first 5,000 of service synthetic engine oil may be used. Follow your vehicle owner’s manual for service intervals.

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART

Please CLICK HERE for ATK Warranty
