ATK has honed the reman torque converter operation to optimize a steady outflow of a variety of products by using and adopting standard operating procedures to supply automotive, high-performance, heavy-duty, and industrial converters. This torque converter has been remanufactured for ATK by CVC (Consolidated Vehicle Converters).

If returning a torque converter core, please see the link below for ATK’s standard core return procedure as the customer is responsible for return shipping charges.

Click Here: ATK Torque Converter Core Return Instructions

ATK TQFM81 Features:

• Pilot to Engine: .825 in. Pilot
• Spline to Turbine: 30 Spline
• TAG ID: ID CODE: 'C' on Pilot Tip
• Note: 32 Spline Stator
• Bosses/Mounting: 4 Studs Mounting
• Factory Code(s): CD4E
• Hub OD: No Drive on 2.140 in. Hub with Inner Bushing
• Mount Thread: M10x1.0 Threads
• Mounting Holes Distance: 8 7/8 in. Bolt Circle
• OEM Make: Ford
• Converter Mount/Diameter: 11 in. Diam
• Interchange part numbers: FM81, TQFM81

  Please CLICK HERE for ATK Warranty
