![SNS2 Series Monotube Shock Absorber with 6.81 in. Travel [Zinc Plated]](https://www.jegs.com/images/mini_750/100/132/132-33-304083.jpg)
Vehicle Info NeededBILSTEINPART NUMBER: 132-33-304083
SNS2 Series Monotube Shock Absorber with 6.81 in. Travel [Zinc Plated]
$24900
Ships on Nov 02, 2026
Lowest Price GuaranteeSNS2 Series Monotube Shock Absorber46 mm Piston 12.99 in. Collapsed / 19.8 in. Extended 1/2 in. Heim Mounts Steel Body Cap Coilover Convertible Zinc Plated Finish
Steel smooth-body monotube shock with a steel body cap that can be converted to a coilover. It is intended for custom and motorsports builds rather than one specific vehicle.
Bilstein B533-304083 SNS2 Series Features:
- Product line: SNS2 Series.
- Internal design: monotube.
- Piston diameter is 46 mm.
- Collapsed length is 12.99 in. and extended length is 19.8 in. That gives 6.81 in. of travel.
- Lower mount: 1/2 in. Heim.
- Upper mount: 1/2 in. Heim.
- Damping: Non-Adjustable.
- Body style: Smooth Body Screw Top (Non-coilover).
- Body material: steel.
- Feature: Steel Body Cap.
- Feature: Coilover Convertible.
- Finish: Zinc Plated.
- Sold as a single unit.
Part TypeShock Absorber
BrandBILSTEIN
Package Height2.95
Package Width2.95
Package Length22.45
Weight7.0 PG
Part CategoryPerformance Parts
Boot IncludedNo
Body TypeSmooth Body Screw Top (Non-coilover)
Lower Mount Type1/2 in. Heim
Shaft Diameter14mm
Quantity1
Piston Diameter46 mm
Collapsed Length (In)12.99 in.
Upper Mount Type1/2 in. Heim
Extended Length (In.)19.8 in.
SeriesSNS2 Series
Body MaterialSteel
Travel Length6.81 in.
Extended Length19.80 in.
Adjustable DampingNon-Adjustable
Part FitmentUniversal
Internal DesignMonotube
FinishZinc Plated
Vendor Part NumberB533-304083
Package Qty1
Package TypeEA
Some parts are not legal for use in California or other states with similar laws / regulations
