Vehicle Info NeededBILSTEINPART NUMBER: 132-AK1054
AK1054 AK Series Shock Absorber
$13689
More than 10 available
Ships on Sep 08, 2026
Lowest Price Guarantee- AK Series - Shock Absorber
- 46mm Monotube Shock Absorber
- Boot Included: Blue Straight
- Internal Design: Monotube
- Finish: Yellow Paint
- Upper Mount Type: Bar Pin
- Lower Mount Type: Stem
- Bilstein AK Series shock absorbers are designed for motorsports applications that require the use of the OE mounting components. Each shock absorber features a monotube design with steel spring valve discs for consistent, fade free performance and superior durability. AK Series shock absorbers are ideal for racers who demand reliable performance that also meets their sanctioning body's mounting requirements.
- Spring Seat Included: No
- Adjustable Damping: Non-Adjustable
- Body Design: Stock Mount Smooth Body
- Rebound @0.52M/S: 1365
- Extended Length (IN): 20.47
- Collapsed Length (IN): 12.92
- Body Diameter (ID): 46mm
- Collapsed Length (MM): 328.1
- Extended Length (MM): 520.0
- Compression @0.52M/S: 500
- Valving Identifier: 165/67
- Piston Type: Linear
- Body Material: Steel
AK1054 Shock Absorber Features:
Part TypeShock Absorber
BrandBILSTEIN
Package Height3.55
Package Width3.55
Package Length26.8
Weight4.41 PG
Part CategoryPerformance Parts
Boot IncludedBlue Straight
Lower Mount TypeStem
Shaft Diameter11mm
Piston Diameter46mm
Collapsed Length (In)12.92 in.
Upper Mount TypeBar Pin
SeriesAK Series
Body MaterialSteel
Travel Length7.67 in.
Extended Length20.47 in.
Adjustable DampingNon-Adjustable
Internal DesignMonotube
FinishYellow Paint
Vendor Part NumberB5AK1054
Package Qty1
Package TypeEA
