V6 Cylinder Heads Bare

Name: V6 Cylinder Heads Bare
Brand: BRODIX
SKU: 158-1600002
Price: 2201.41 USD
Availability: InStock

^$2,201⁴¹

Ships on 09/18/2026

Lowest Price Guarantee

Angled Plug

Bare
Angled Plug
Intake Volume: 194cc
Combustion Chamber: 67cc

Specs and Related Components
Torque Heads: 70 ft-lb
Torque Rocker Studs: 40-45 ft-lb
Intake Gaskets: Fel-Pro 375-1203
Valve Cover Gaskets: Fel-Pro 375-1601
Head Gaskets: Fel-Pro 375-1002
Exhaust Gaskets: Fel-Pro 375-1403
Head Bolts: Manley 660-42313 (V8 Kit)
Head Bolt Washers: Manley 660-42102 (V8 Kit)
Head Studs: ARP 070-234-4301 (V8 Kit)
Accessory Bolt Holes Are Drilled
Spark Plug Starting Points: Champion 192-404 (RN12YC) or Autolite 417-3924for Pump Gas, NGK 739-R5671A-8 for Racing Gas
Spring Pockets: 1.550 Out of the Box, May Be Cut to 1.625 - No Larger or Deeper
Valve Angle: 23°
Pushrod Slots: Standard
Rocker Arms: Standard
Lifters: Standard
Valve Centerline: Standard
Intake Manifold: Edelbrock Performer 90° V6 (Dual Plane) 350-2111

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART

The 90° V6 Aluminum Cylinder Head is another fine product offered by Brodix and is available in two different intake ports. The 194cc intake port is recommended for a low rpm, Pro Street style engine. The 210cc intake port is recommended for a larger cubic inch engine, higher rpm range, and racing environment. The Brodix V6 heads are made of virgin A-356 aluminum material and have ductile iron seats and solid phosphorous bronze guides. Helicoils are installed in the rocker stud bosses to assure stability. These heads are sold in pairs and available bare or assembled.

Assembled Heads Include:
