Cylinder Head Gasket 1996-99 GM 2.4L LD9 (EGR)
InfoVehicle Info Needed
COMETIC GASKETSPART NUMBER: 245-C5298-051

Cylinder Head Gasket 1996-99 GM 2.4L LD9 (EGR)

$6488$101.37You Save$36.49
1 left in stock
ShippingShips on Nov 02, 2026
Lowest PriceLowest Price Guarantee

2.4L LD9
    Cylinder Head Gasket
  • 1996-99 GM 2.4L LD9 (EGR)
  • Bore: 3.595"
  • Compressed Thickness: .051"

    Cometic Gaskets 245-C5298-051 Features:

    Oldsmobile LD9 Quad 4 .051" MLS Cylinder Head Gasket, 3.595" Bore, With EGR

Cometic Multilayer Steel (MLS) Gaskets are designed to provide the best possible seal for naturally-aspirated, boosted, or nitrous-fed engines. These head gaskets are made from 3 to 5 layers of spring stainless steel, offering a stronger base material than standard cylinder head gaskets. Viton-coated outer layers create a superior seal not available with other steel or copper gaskets. Cometic MLS Cylinder Head Gaskets reduce bore distortion but can still endure extreme cylinder pressures. Sold individually.

Show More

Features:

  • Made from stainless spring steel
  • Excellent rebound characteristics and corrosion resistance
  • Viton rubber coating (.001'' thick) is bonded to outer layer of gaskets
  • Designed to withstand serious cylinder pressures without machining for installation of locking wire

Installation Notes:

  • Not designed for use on engines with O-rings or receiver grooves
  • Always refer to the fastener manufacturer to determine accurate torque values
  • A surface finish of 50 RA (roughness average) or finer is recommended for proper gasket seal
  • Cometic Cylinder Head Gaskets go on dry because they're coated with a sealant (adding another sealer can hinder gasket performance)
Part TypeHead Gasket
Product LineCometic 4-Cylinder Chevy Cylinder Head Gaskets
BrandCOMETIC GASKETS
Package Height0.5
Package Width10.0
Package Length24.0
Weight1.135 PG
Part CategoryPerformance Parts
Part FitmentSemi Universal
Vendor Part NumberC5298-051
Package Qty1
Package TypeEA
Some parts are not legal for use in California or other states with similar laws / regulations
