Beehive Valve Spring Universal

Name: Beehive Valve Spring Universal
Brand: COMP CAMS
SKU: 249-26056-1
Price: 44.95 USD
Availability: InStock

^$44⁹⁵

Ships on Sep 03, 2026

Lowest Price Guarantee

Universal

Universal
O.D. Base: 1.454
1/pkg

SpecsOD: Top 1.185" Bottom 1.454"ID: Top .731" Bottom 1.000"Seat Pressure: 160 lbs @ 1.80'Open Pressure: 420 lbs @ 1.150'Coil Bind: 1.100"Spring Rate: 400 lbs/in
Valve Springs; Dual Valve Springs; Single Valve Springs; Beehive Springs; Conical Springs; Valve Lift; Max Lift; Spring Kit

Beehive springs are one of the best ways to modernize your valvetrain and free up horsepower. This includes one single valve spring. See our 26056-4 for a pack of 4.

Part TypeValve Spring
BrandCOMP CAMS
Package Height2.0
Package Width4.0
Package Length6.0
Weight0.8 PG
Part CategoryPerformance Parts
CoatedNo
Coil Bind Height1.1 in (27.94 mm)
Damper Spring IncludedNo
Spring Rate400 lbs./in.
PositionN/A
Open Height1.15 in (29.2 mm)
Open Pressure (Lbs.)420
Installed Pressure (Lbs.)160
QuantitySold individually
Installed Height1.8 in (45.72 mm)
Valve Spring StyleBeehive
Outside Diameter Of Outer Spring1.185 in (30.1 mm)
Inside Diameter Of Outer Spring1 in (25.4 mm)
Inside Diameter0.731/1.112
Spring TypeSingle
Spring Rate (Lbs./In.)400
Part FitmentSemi Universal
Outside Diameter1.204 in (30.6 mm)
Number Of Springs Per ValveSingle
Camshaft TypeHydraulic
Vendor Part Number26056-1
Package Qty1
Package TypeEA
