COMP CAMSPART NUMBER: 249-7256-16

Conical Valve Springs Rate: 485 lbs

Name: Conical Valve Springs Rate: 485 lbs
Brand: COMP CAMS
SKU: 249-7256-16
Price: 432.95 USD
Availability: InStock

^$432⁹⁵

Ships on 09/09/2026

Lowest Price Guarantee

Conical Valve Springs

Rate: 485 lbs
Inner Diameter: .660'' Top, .990'' Bottom
Outer Diameter: 1.060'' Top, 1.390'' Bottom
Seat Load: 160 lbs at 1.900''
Open Load: 495 lbs at 1.210''
Coil Bind Height: 1.165''
16/pkg

Valve Springs; Dual Valve Springs; Single Valve Springs; Beehive Springs; Conical Springs; Valve Lift; Max Lift; Spring Kit

Part TypeValve Spring Kit

BrandCOMP CAMS

Package Height4.3

Package Width4.8

Package Length5.7

Weight3.1 PG

Part CategoryPerformance Parts

CoatedNo

Coil Bind HeightOEM

Damper Spring IncludedNo

Spring Rate485 lbs./in.

QuantitySold as a set of 16

Valve Spring StyleConical

Outside Diameter Of Outer Spring1.39 in (35.3 mm)

Inside Diameter Of Outer Spring0.99 in (25.146 mm)

Spring TypeSingle

Spring Rate (Lbs./In.)486

Part FitmentSemi Universal

Number Of Springs Per ValveSingle

Camshaft TypeN/A

Vendor Part Number7256-16

Package Qty1

Package TypeEA
