Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Conical Valve Springs
- Conical Valve Springs
- Rate: 362 lbs
- Inner Diameter: 1.070'' Top, .866'' Bottom
- Outer Diameter: 1.454'' Top, 1.250'' Bottom
- Seat Load: 100 lbs at 1.750''
- Open Load: 281 lbs at 1.250''
- Coil Bind Height: 1.135''
- 12/pkg
Part TypeValve Spring Kit
BrandCOMP CAMS
Package Height2.12
Package Width8.5
Package Length13.75
Weight2.15 PG
Part CategoryPerformance Parts
CoatedNo
Coil Bind Height1.135 in (28.829 mm)
Damper Spring IncludedYes
Spring Rate322 lbs./in.
PositionN/A
Open Height1.25 in (31.8 mm)
Open Pressure (Lbs.)281
Installed Pressure (Lbs.)100
QuantitySold as a set of 12
Installed Height1.75 in (44.45 mm)
Valve Spring StyleConical
Outside Diameter Of Outer Spring1.25 in (31.8 mm)
Inside Diameter Of Outer Spring0.885 in (22.479 mm)
Inside DiameterN/A
Spring TypeSingle
Spring Rate (Lbs./In.)362
Outside DiameterOEM
Number Of Springs Per ValveSingle
Camshaft TypeHydraulic
Vendor Part Number982-12
Package Qty1
Package TypeEA
