Magnum 282S Mechanical Flat Tappet Camshaft Small Kit
Lift: .495"/.495"
Duration: 282°/282°
Lobe Separation Angle: 110°
RPM Range: 2500-6000

340-360 Street Machine / Bracket Race with 2500 stall, 9.5:1 to 10.5:1 comp. & 3.91 to 4.10 gear. Aftermarket manifold & 650 to 750 CFM carb.



Operating Range:	2500-6000 RPM
Duration Advertised:	282° Intake / 282° Exhaust
Duration @ .050' Lift:	236° Intake / 236° Exhaust
Valve Lift:	.495' Intake / .495' Exhaust
Lobe Separation Angle:	110°

273, 360, 318, AMC, Dodge, Mopar, Plymouth, Dart, Road Runner, Charger, Challenger, 383, 400, 440, 426, HEMI, 426 Wedge, 426 HEMI, RB, B, HEMI, 392, Chrysler, LA


340-360 street machine/bracket race with 2500 stall, 9.5:1-10.5:1 compression and 3.91 to 4.10 gear. Aftermarket manifold & 650-750 CFM carb.

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
