AVS2 Carburetor 650 CFM, Manual Choke - Black Powder-Coated Finish

Name: AVS2 Carburetor 650 CFM, Manual Choke - Black Powder-Coated Finish
Brand: EDELBROCK
SKU: 350-19053
Price: 499.95 USD
Availability: InStock

^$499⁹⁵

Ships on 10/28/2026

Lowest Price Guarantee

650 CFM
Manual Choke

AVS2 Carburetor

650 CFM

Manual Choke

Square Flange

Non-EGR

Black Powder-Coated Finish

Sold Individually

Edelbrock 19053

Features:

(1) Base gasket and (1) top gasket included
Ideal for use with street performance small and big-block engines utilizing a dual or single-plane intake manifold
Annular-flow primary boosters improve off-idle and cruising performance
(8) Equally-spaced orifices improve fuel metering from idle to the main circuit
Timed and full vacuum ports for advancing ignition timing

Technical Specifications:

Bore diameters: 1.440 in. primary, 1.750 in. secondary
Main venturi diameter: 1.190 in.
Primary metering jet: .101 in.
Secondary metering jet: .098 in.
Metering rod size: .070 in. x .037 in.
5 in. Hg (vacuum) Orange step-up spring
Body height: 3.250 in.

Notes:

Requires the use of a fuel filter between the fuel pump and carburetor
NOT compatible with alcohol, race fuel or E85
Will work with Ford automatic overdrive transmissions (AOD) - requires Lokar bracket 625-SRK-4000
Cannot be converted to an electric choke

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART

Since founder Vic Edelbrock Sr. began building performance intake manifolds in 1938, Edelbrock has grown into one of the most trusted names in American high-performance parts, from carburetors and intake manifolds to cylinder heads, crate engines, and EFI systems. JEGS has spent decades supplying Edelbrock components to racers, engine builders, and street enthusiasts, backing this extensive lineup with in-house technical support, fast shipping, and a Price Match Guarantee so you can choose proven Edelbrock parts with confidence.

AVS2 Series, The Next Generation Of Edelbrock Carburetors

Edelbrock AVS2 carburetors feature annular flow primary boosters with enhanced calibration for improved off-idle and cruising performance. This design features eight equally spaced holes to improve fuel metering and atomization to eliminate any flat spots when transitioning from idle to throttle. Ideal for use with a wide variety of small-block and big-block engines with either dual-plane or single-plane intake manifolds. The AVS2 includes both timed and full vacuum ports for ignition advance.

The elbrock AVS2 carburetors represent a refined evolution in fuel-delivery technology, engineered to eliminate flat spots and deliver smooth, efficient throttle response. These carbs feature annular-flow primary boosters—a design that utilizes eight uniformly spaced orifices to enhance fuel atomization and metering, resulting in seamless performance from idle through acceleration.

Whether you're running a small-block or a big-block engine—paired with a dual-plane or single-plane intake—the AVS2 is calibrated for versatility and precision. It includes both timed and full vacuum ports to accommodate modern ignition systems.

Why Choose AVS2?

Improved drivability: Annular boosters smooth out throttle transitions and offer crisp off-idle control.
Street-smart tuning: Compared to the older AVS model, the AVS2 shines in real-world driving conditions—offering better fuel economy, smoother cold starts, and superior low-RPM cruising.
Adaptable configurations: Available in 500-, 650-, and 800-CFM options, with choices in choke (manual or electric) and finish (satin, black, or chrome).

This avs2 carburetor is a standout for anyone seeking a refined, all-around performance upgrade. If you’re installing an avs carb, you're gaining smoother throttle response, better fuel control, and street-ready flexibility. And if you're upgrading your ride with an avs2 carb, you’ll appreciate the combination of tunability, reliability, and drivability packed into these carbs.

Experience a carburetor engineered not just for power, but for polished performance—every drive.

Part TypeCarburetor

Product LineEdelbrock AVS2 Carburetors

BrandEDELBROCK

Package Height6.5

Package Width7.4

Package Length13.3

Weight8.55 PG

Part CategoryPerformance Parts

UsageAutomotive

FlangeSquare Bore

ChokeManual
