Installation Notes:

• The brass lined crossover and inserts protect the aluminum from salt water corrosion.
• Port exit dimensions: 1.61" x 1.93"
• Manifold height: (A) 4.45" , (B) 6.00"
• Carb Pad Height: 5.22" Click here to determine carburetor pad height.
• Recommended intake manifold bolts - 350-8564.
• Recommended intake gasket - 555-210102
• Accepts square-bore and spread-bore carbs.
• Requires electric choke carb, Has no provisions for exhaust heated chokes.



  Carburetor Recommendations:
• Edelbrock Performer 600cfm Marine Carburetor - 350-1409 (for marine use only)
• Edelbrock Performer 750cfm Marine Carburetor - 350-1410 (for marine use only)

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
