Technical Specs:

• Features an improved runner design with an incredible 5.38 square-inches of runner area in the plenum
• CNC Port Matched for Edelbrock/Musi Victor 24° CNC 377cc heads (350-61409)
• Big Block Chevy Tall Deck (10.2") Blocks without Manifold Spacers
• Port Exit Dimensions: 1.72" w x 2.45" h
• Recommended Intake Gasket; Jegs 555-210100 or Fel-Pro 375-1275
• 4500 Carburetor Flange
• Manifold Height: (A) 7.50", (B) 7.50"
• Manifold Flange Reference: (R) 1.38", (F) 1.06", (W) 1.72", (H) 2.45", (CH) 7.50", (CA) 0°

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
