Made in USA
Super Victor 351W EFI Ford Intake Manifold Polished
Product Discontinued
EDELBROCKPART NUMBER: 350-292451

Super Victor 351W EFI Ford Intake Manifold Polished

Currently Unavailable

This product is no longer available. Please call customer service for assistance at 1-800-345-4545.

Ford Super Victor EFI
  • Small Block Ford 351 Windsor
  • With 9.5" deck standard block
  • 4150 Throttle Body Flange
  • 4500-8500 RPM Range
  • Polished Finish
  • EFI

    Designed for high rpm or large displacement competition 351 Windsor Ford V8s with a deck height of 9.5" which are used in drag racing or oval track engines operating between 4500 and 8500 rpm. This intake can be used with ported factory cast iron heads, however aftermarket aluminum heads are recommended, such as Edelbrock Victor Jr. heads 350-77169, Victor heads 350-77219 or equivalent for ultra high-horsepower. Runners have a 3.20 square-inch cross sectional area.

    Installation Notes:
  • Recommended intake gasket: Fel-Pro 375-1262, Fel-Pro 375-1262R or Jegs 555-210201
  • Manifold height: (A) 6.25', (B) 6.25'
  • Carb pad height = 6.25' View Manifold 'A/B' Measurement Guide.
  • Square bore 4150 style throttle body flange
  • Includes Nitrous Bosses
  • No rear water crossover
  • MSD distributor 121-8578 must be used to clear the front water crossover
  • Use with Edelbrock Ford Fuel Rail Kit 350-3620
  • Throttle body recommendations: 4150 4V throttle body 350-38783 or EFI elbow 350-3849 with
    90mm Ford style throttle body 350-3818
Part TypeIntake Manifold
BrandEDELBROCK
Package Height7.0
Package Width14.5
Package Length24.0
Weight26.0 PG
Part CategoryPerformance Parts
Runners RemovableNo
Number Of CarbsNone, For Fuel Injection
Supplemental Bosses Cast-InYes
Plenum MaterialAluminum
EmissionWithout EGR
Engine Make/SizeFord 5.8L/351W
Basic Operating Rpm Range4,500-8,500
Base FinishPolished
Rpm Range4500-8500
Injection StyleMulti-port
Supplemental Boss QuantityEight
Base MaterialAluminum
Plenum FinishPolished
Aftermarket Fuel Rail RequiredYes
Engine Block StyleStock/OEM standard deck
UsageRacing
Throttle Body IncludedNo
PositionN/A
QuantitySold individually
Cylinder Head TypeStandard
Injectors IncludedNo
Fuel Rails IncludedNo
Intake Section IncludedComplete
EgrWithout EGR
Supplemental Bosses MachinedNo
Runners IncludedNo
Vendor Part Number292451
Package Qty1
Package TypeEA
