Product Discontinued
EDELBROCKPART NUMBER: 350-2968
Victor High-Port Intake Manifold Small Block Chevy High Port 23° Cylinder Heads
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Victor High-Port
- Victor High-Port Intake Manifold
- Small Block Chevy High Port 23° Cylinder Heads
- 4150-style Square Bore Carb Flange
- 4500-8500 RPM Range
Ideal for bracket race and high rpm circle track applications, this manifold is designed for raised-port 23° heads such as Pontiac #10045434, #10033867 and Chevrolet Raised Runner Bowtie heads #10051101. The deep plenum design is beneficial for restrictor plate applications. Runners have a 3.0 square-inch cross-section. Relief for center water outlets included. Installation Notes:
- Port exit dimensions: 1.18' x 1.85'
- Distance from bolt hole centerline to port roof 1.10'; to port floor 0.75'
- Carb pad height = 5.35' with 0° carb angle.
- Recommended intake gasket; Fel Pro 375-1263
Part TypeIntake Manifold
BrandEDELBROCK
Package Height6.2
Package Width11.4
Package Length24.0
Weight18.6 PG
Part CategoryPerformance Parts
UsageRacing
Number Of CarbsOne
EmissionWithout EGR
Rpm Range4500-8500
Cylinder Head TypeStandard
Engine Make/SizeChevy Small Block (262-400)
Package Qty1
Package TypeEA
