Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Big Block Chevy 454ci TBI 1987-1990
- 1987-1990 Big Block Chevy TBI 454ci
- OE Throttle Body Injection Flange (EGR)
- Idle-5500 RPM Range
- Polished Finish
The Performer 454 TBI manifold delivers outstanding performance for the street with complete emissions compatibility. With the complete Edelbrock Total Power Package 0-60 times improved by 1.70 seconds (includes manifold #350-3764, cam kit #350-2162 and Tubular Exhaust System). Performer #350-3764 is for 1987-90 Chevrolet and GMC trucks with Mark IV 454 c.i.d. throttle body injected V8 engines.Installation Notes:
- Port exit dimensions: 1.41" x 1.59"
- Manifold height: (A) 4.30" , (B) 6.45"
- Carb Pad Height: 5.37" Click here to determine throttle body pad height.
- Use factory GM intake gasket #10181398
- Use stock throttle body injection unit.
- Accepts stock EGR in stock location.
- 1987-90 Chevy 454 trucks require Edelbrock GM TBI throttle bracket 350-8019.
Part TypeIntake Manifold
BrandEDELBROCK
Package Height6.8
Package Width12.1
Package Length23.8
Weight23.05 PG
Part CategoryPerformance Parts
Runners RemovableNo
Number Of CarbsNone, For Fuel Injection
Supplemental Bosses Cast-InNo
Plenum MaterialAluminum
EmissionWith EGR
Engine Make/SizeChevy Big Block (396-502)
Basic Operating Rpm RangeIdle-5,500
Base FinishPolished
Rpm RangeIdle -5500
Injection StyleThrottle body
Base MaterialAluminum
Plenum FinishPolished
Aftermarket Fuel Rail RequiredNo
Engine Block StyleStock/OEM standard Deck
UsageStreet/Hi-Performance
Throttle Body IncludedNo
PositionN/A
QuantitySold individually
Cylinder Head TypeOval Port- Small
Injectors IncludedNo
Fuel Rails IncludedNo
Intake Section IncludedComplete
EgrYes
Supplemental Bosses MachinedNo
Runners IncludedNo
Vendor Part Number37641
Package Qty1
Package TypeEA
No Questions
No Reviews
