Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Chevy LS Carbureted Intake Manifold Kits
- GM Gen III LS
- Cathedral Port
- 4-bbl Square-bore Carburetor Flange
- Includes Timing Control Module
- 1500 to 6500 RPM Range
- Polished Finish
This powerful manifold is designed for the popular Chevrolet LS1 5.7L small-block V8 originally used in 1997-Up Corvette and 1998-2002 Camaro/Firebird. It also fits the Corvette LS6 and Gen III LR4 4.8L, LM7 5.3L, and LQ4 6.0L engines. For maximum power and a broad torque curve from 1500-6500 RPM, this manifold allows the use of a carburetor on these originally computer-controlled engines. It made 410 HP and 418 ft/lbs TQ in dyno tests with camshaft 350-2215 and carburetor 350-1413.Installation Notes - Port Exit Dimensions: .98" Wide x 2.72" Tall
- Uses LS1/LS6-style individual port O-ring seals
- Recommended intake gasket; Fel-Pro 555-210800
- Manifold Height: (A) 4.50' , (B) 5.40'; Carb pad height = 4.95'
- View Manifold 'A/B' Measurement Guide.
- Includes intake manifold, wiring harness, throttle cable/transmission kickdown cable bracket, and timing control module
- Throttle/trans bracket compatible with TH350, 200R-4 & TH700R-4 transmissions
- Timing control module and wiring harness works with LS1 24x reluctor wheel(crank trigger) applications only
- LS1(24x) applications can be identified by the rear mounted cam position sensor that is black in color
- LS2 applications with 58x reluctor wheel(crank trigger) use MSD ignition controller 121-6012
- LS2(58x)applications can be identified by the timing cover mounted cam position sensor that is grey in color
- Polished Finish
Part TypeIntake Manifold
BrandEDELBROCK
Package Height9.4
Package Width16.2
Package Length23.9
Weight23.2 PG
Part CategoryPerformance Parts
Engine Block StyleStock/OEM standard deck
UsageStreet/Hi-Performance
Number Of CarbsOne
Intake MaterialAluminum
PositionN/A
Intake StyleDual plane
EmissionWithout EGR
QuantitySold as a kit
Cylinder Head TypeStandard
Intake FinishPolished
Carburetor QuantityOne
Engine Make/SizeChevy Small Block LS1
Intake Section IncludedComplete
Basic Operating Rpm Range1,500-6,500
EgrWithout EGR
Rpm Range1500-6500
Vendor Part Number71181
Package Qty1
Package TypeEA
