Vehicle Info NeededEDELBROCKPART NUMBER: 350-7136
Pro-Flo XT EFI Intake Manifold BB-Chevy
$99595
Ships on 09/15/2026
Lowest Price GuaranteeBig Block Chevy Pro-Flo XT EFI
- Pro-Flo XT EFI Intake Manifold
- Big Block Chevy
- Rectangle Port Heads
- 1500-6500 RPM Range
- Satin Finish
This Pro-Flo XT intake is engineered for high performance 396-502 c.i.d. Chevy V8's with rectangular-port cylinder heads. A large plenum and tapered runners deliver maximum horsepower and broad torque throughout the rpm range of 1500-6500 rpm). It features a 90mm throttle body opening for maximum performance
Installation Notes - Manifold Dimensions: (A) 9.80", (B) 10.00", (C) 17.80', (D) 0.00', (E) 10°
- Manifold not equipped with EGR.
- Recommended intake gasket: Jegs p/n 555-210101
- Throttle Body Recommendations: Edelbrock Pro-Flo XT Throttle Bodies p/n 350-3869 or p/n 350-38693
- Standard LS1 throttle bodies can also be used with Edelbrock adapter p/n 350-2737
- Compatible with Edelbrock BB-Chevy Oval-Port XT fuel rail kit p/n 350-3658
- Compatible with Pico or standard style injectors
Emissions Note:
This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.
CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
Part TypeIntake Manifold
BrandEDELBROCK
Package Height12.6
Package Width13.9
Package Length25.1
Weight27.81 PG
Part CategoryPerformance Parts
Throttle Body Bore Size (Mm)90
Runners RemovableNo
Number Of CarbsNone, For Fuel Injection
Supplemental Bosses Cast-InYes
Plenum MaterialAluminum
EmissionWithout EGR
Engine Make/SizeChevy Big Block
Basic Operating Rpm Range1,500-6,500
Base FinishNatural
Rpm Range1500-6500
Injection StyleMulti-port
Supplemental Boss QuantityEight
Base MaterialAluminum
Plenum FinishNatural
Aftermarket Fuel Rail RequiredYes
Engine Block StyleStock/OEM standard Deck
UsageRacing
Throttle Body IncludedNo
PositionN/A
QuantitySold individually
Cylinder Head TypeRectangular Port
Injectors IncludedNo
Fuel Rails IncludedNo
Intake Section IncludedComplete
EgrWithout EGR
Supplemental Bosses MachinedYes
Runners IncludedYes
Vendor Part Number7136
Package Qty1
Package TypeEA
