Edelbrock 7521-BP Features:

Edelbrock 7521-BP RPM Air-Gap intake manifold is designed for Small-Block Ford 289-302 CID based V8's including 331-347 stroker applications. The RPM Air-Gap incorporates the same race-winning technology that’s been used on our Victor Series competition intakes and is the perfect manifold for hot rodders, street custom enthusiasts, bracket racers or any builder looking for optimum performance in the 1,500-6,500 RPM range with a serious look of horsepower under the hood. The Air-Gap design features an open air space under the plenum that separates the runners from the hot engine resulting in a cooler, denser charge for more power. The 7521 RPM Air-Gap features larger runners (7% at the plenum entries) than the standard 7121 Performer RPM design that is beneficial to larger CID stroker engines. This 7521-BP version comes with a beautiful reflective Black Plasma finish that is durable and easy to maintain. The Plasma finishes are applied by a fully automated 7 stage prewash and 4 stage finish. A durable clear powder coat finises the process. The 7521 includes nitrous bosses but no provision for exhaust heated chokes and no exhaust crossover. Edelbrock carbs will work with Ford automatic overdrive trans (AOD) when used with Lokar bracket SRK-4000.

• Long runner high-rise design for broad torque curve
• 7 stage prewash and 4 stage coating for durability and beauty
• Will not fit 255 c.i.d. V8
• Not ideal for 289
• Recommended intake gasket: Edelbrock 7220
• Manifold Height: A-4.300 in., B-5.500 in.
• Carb pad height: 4.900 in.
• Carb recommendations: Edelbrock AVS2 650, Performer Series 600-750, or VRS-4150 650 cfm
• For automatic transmissions use 1483 and 1490 or 1844.
• Port exit dimensions: 1.040 in. x 1.850 in.
• Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant Edelbrock 1076, DO NOT USE END SEALS GASKETS
• Edelbrock 8524 intake manifold bolt kit which includes hardened washers to ensure proper torque and prevent galling of the aluminum is highly recommended.

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
