![Factory Race 2.5 x 16 Smooth Body Remote Shock Absorber w/DSC Adjuster [Gray Cerakote]](https://www.jegs.com/images/mini_750/400/433/433-981-25-004-3.jpg)
Vehicle Info NeededFOX RACING SHOXPART NUMBER: 433-981-25-004-3
Factory Race 2.5 x 16 Smooth Body Remote Shock Absorber w/DSC Adjuster [Gray Cerakote]
$1,06495
Ships on 11/03/2026
Lowest Price GuaranteeFactory Race 2.5 x 16 Smooth Body Remote Shock Absorber w/DSC AdjusterUniversal Fit, 2.5 in. Body Diameter 15.95 in. Travel, 41.45 in. Extended Length DSC Dual Speed Compression Adjuster 7/8 in. Shaft Steel Body Sold Individually
This Factory Race Series smooth body shock absorber is a non-vehicle-specific damper for custom, prerunner and race builds. It has a 2.5 in. body and 15.95 in. of travel, so check your shock mounts and chassis geometry before you order.
FOX 981-25-004-3 Features:
- Body diameter is 2.5 in.
- Shaft diameter is 7/8 in.
- Usable travel is 15.95 in.
- Extended length is 41.45 in. and compressed length is 25.5 in.
- The body is steel with a gray cerakote finish.
- The remote reservoir holds extra oil and nitrogen to help control heat during long runs.
- Mounting uses eyelet top and bottom mounts. Eyelet length is 1.95 in.
- Mounting hole and bushing size is 1/2 x 1-1/2 in.
- Reservoir measures 2.55 in. x 14.00 in.
- Reservoir hose is -10 AN and 18 in. long.
- Damping is tuned with DSC Dual Speed Compression Adjuster.
Fitment and Application:
- Universal application; verify mounting dimensions before installation.
- Sold individually.
Part TypeShock Absorber
BrandFOX RACING SHOX
Package Height10.0
Package Width19.0
Package Length32.0
Weight18.0 PG
Part CategoryPerformance Parts
Remote ReservoirYes
Rod Diameter7/8 in.
Lower Mount TypeEyelet
Compressed Length25.5 in.
Upper Mount TypeEyelet
Reservoir Hose Length18 in.
SeriesFactory Race
Body MaterialSteel
Reservoir Diameter2.55 in.
Body Diameter2.5 in.
Travel Length15.95 in.
Extended Length41.45 in.
Reservoir Length14 in.
Adjustable CompressionYes
Part FitmentUniversal
Reservoir Hose Inside Diameter-10 AN
FinishGray Cerakote
Vendor Part Number981-25-004-3
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
