![Performance Elite 2.5 x 12 Coil-Over Remote Shock Absorber w/DSC Adjuster [Clear Zinc Plated]](https://www.jegs.com/images/mini_750/400/433/433-981-25-118-3.jpg)
Vehicle Info NeededFOX RACING SHOXPART NUMBER: 433-981-25-118-3
Performance Elite 2.5 x 12 Coil-Over Remote Shock Absorber w/DSC Adjuster [Clear Zinc Plated]
$87995
Ships on 11/03/2026
Lowest Price GuaranteePerformance Elite 2.5 x 12 Coil-Over Remote Shock Absorber w/DSC AdjusterUniversal Fit, 2.5 in. Body Diameter 12 in. Travel, 32.45 in. Extended Length DSC Dual Speed Compression Adjuster 7/8 in. Shaft Steel Body Sold Individually
Builders who fabricate their own suspension use this Performance Elite Series coil-over shock absorber to fill a known mounting length. It measures 32.45 in. extended with 12 in. of travel.
FOX 981-25-118-3 Installation Notes:
- Universal application; verify mounting dimensions before installation.
- Sold individually.
Key Dimensions:
- Body diameter is 2.5 in.
- Shaft diameter is 7/8 in.
- Usable travel is 12 in.
- Extended length is 32.45 in. and compressed length is 20.45 in.
- The body is steel with a clear zinc plated finish.
- The remote reservoir holds extra oil and nitrogen to help control heat during long runs.
- Mounting uses eyelet top and bottom mounts. Eyelet length is 1.9 in.
- Mounting hole and bushing size is 1/2 x 1-1/2 in.
- Reservoir measures 2.55 in. x 10 in.
- Reservoir hose is -8 AN and 18 in. long.
- Damping is tuned with DSC Dual Speed Compression Adjuster.
- Service seal kit part number: 803-04-034.
Part TypeShock Absorber
BrandFOX RACING SHOX
Part CategoryPerformance Parts
Remote ReservoirYes
Rod Diameter7/8 in.
Lower Mount TypeEyelet
Compressed Length20.45 in.
Upper Mount TypeEyelet
Reservoir Hose Length18 in.
SeriesPerformance Elite
Body MaterialSteel
Reservoir Diameter2.55 in.
Body Diameter2.5 in.
Travel Length12 in.
Extended Length32.45 in.
Reservoir Length10 in.
Adjustable CompressionYes
Part FitmentUniversal
Reservoir Hose Inside Diameter-8 AN
FinishClear Zinc Plated
Package Qty1
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
