uC-10 Wiring Diagram

Haltech HT-068000 uC-10 Digital 10 in. Dash Includes:

• Haltech uC-10 10-inch Color Display Dash
• 34-pin main connector harness and spare pins
• DTM-4 to DTM-4 CAN cable - 3000mm (120”)
• USB-A to USB-C cable
• Mounting screws (M5x8mm)
• (2) Momentary switches, pre-terminated with cables (22AWG, 800mm)
• Glass mount Wi-Fi antenna
• USB-C Dust Cap
• Quick start guide

Haltech HT-068000 uC-10 Digital 10 in. Dash Features:

• Full-colour, optically-bonded TFT screen
• 70° minimum viewing angle (vertical and horizontal)
• 1280 x 480 resolution, 600+ lumens
• IP64 (Dust-tight and protected against water splashes)
• 6-digit odometer
• 512MB of on-board looped data logging
• NSP compatible
• 10 x user configurable AVIP's
• 4 x user configurable DPO's
• 4 x user configurable SPI's
• 1 x dedicated Tacho Input
• 1 x dedicated alternator excite
• 2 x Ambient light sensors

Haltech HT-068000 uC-10 Digital 10 in. Dash Notes:

• Compatible With:
  • All current Haltech ECUs via CAN
  • Plug'n'Play compatible with the following aftermarket ECU brands:
    • Hondata
    • Link G4
    • MaxxECU
    • Microtech
    • MoTeC M1 series
    • MoTeC hundred series- (M400,600,800 gold box ECUs)
    • Syvecs
  • OBDII functionality requires adapter cable HT-135003 (sold separately)
