Seal Types:

• FKM Fluorocarbon for Oil, Water, Transmission Fluid, Pump Gas, Race Gas, E85 and Diesel applications
• EPDM seals for Methanol (Methyl Alcohol), Ethanol (Ethyl Alcohol) and Nitromethane applications Features:
• Replaces Any Fitting in Any Location
• Available for virtually all Fuel, Oil, and Water Applications
• Will not wear out
• Connectors swivel 360° after connection has been made
• Avoids stripping, cross-threading, and over-tightening
• Any 30 series Pro-Compact plug will work with any 30 series Pro-Compact socket
• Maximum Operating Pressure: 200 psi
• Operating Temperature: -40° to 350° F; -40° to 177° C
• Works with most steel-braided, lightweight black, and push-to-lock hose styles except PTFE
• Jiffy-tite fittings permit fluid to flow in both directions



  Notes:
• Fittings should not be used on brake lines.
• Push Lock Hose End Fittings uses "Push Loc" Style Hose
• Hose Barb fittings uses standard braided hose but requires a clamp or crimp collar
• Pro-Compact Series cannot be used with 2000, 3000, or 5000 series quick connect sockets, plugs transmission kits or carburetor kits.
