Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Single Valve Springs16/pkg
.550 in. Lift Beehive Single Valve Springs OD: 1.061 in. ID: .738 in. Seat Load: 80 lbs/in @ 1.640 in. Open Load: 185 lbs/in @ 1.090 in. Coil Bind: 1.020 in. Rate: 191 lbs/in Set of 16
LUNATI/HOLLEY 74813-16 Features:
In any spring, the inner diameter experiences significantly more stress than the outside. The ovate multi-arch wire design of these revolutionary valve springs places more material on the inner diameter of the spring, which more evenly distributes stress throughout the wire cross-section and increases the overall life of the spring. Other features of the Signature Series Ovate Beehive Valve Springs include reduced mass in the retainer end of the spring, which increases RPM potential, and reduced coil surging for more valve control and longevity. Lastly, a thinner cross-section wire gives more coil bind clearance to allow for camshafts with higher lift or higher ratio rocker arms. The Signature Series Ovate Beehive Valve Springs are the ultimate in cutting-edge valvetrain performance.Available single or dual, these valve springs are formed from chrome silicon wire & finished using a cutting-edge heat treatment. This advanced heat-set takes the load loss out of the springs during manufacturing (instead of their first use) to extend spring life and ease break-in. The springs offer excellent fatigue resistance & load loss characteristics ideally suited to oval track or drag racing.
Show More
Part TypeValve Spring Kit
Product LineLunati Valve Springs
BrandLUNATI
Package Height2.3
Package Width2.9
Package Length10.8
Weight1.75 PG
Part CategoryPerformance Parts
Part FitmentSemi Universal
Vendor Part Number74813-16LUN
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
