6912-07 RST Street Twin Disc Clutch Kit 1997-2013 GM LS-X, 2001-2017 Ford 4.6/5.0L, 1-1/8 x 26
InfoVehicle Info Needed
MCLEODPART NUMBER: 673-6912-07

6912-07 RST Street Twin Disc Clutch Kit 1997-2013 GM LS-X, 2001-2017 Ford 4.6/5.0L, 1-1/8 x 26

$83250$925.00You Save$92.50
More than 10 available
Lowest PriceLowest Price Guarantee

Ford/GM
    RST Street Twin Clutch
  • 1997-2012 GM V8 5.7/6.0/6.2/7.0L & GM LSX
  • 2005-2010 Ford Mustang V8 4.6/5.0/5.4L
  • 1-1/8'' x 26 Spline
  • Fits 164, 176, 180, 184 Tooth Flywheels

  • GM - Needs LS1 Flat style flywheel with this application.
  • Ford - Requires flywheel with 6.250 ID. Not Intended for GT 500.
  • Designed to fit 164, 176, 180, or 184-tooth flywheels. Will not work with factory flywheel if If the center hub of the flywheel is recessed.
  • RST:9.687" Dia. Disc:Chevy:1997-13 LS-X:2001-17 Ford 4.6/5.0L:1-1/8x26
  • Intended for the high horsepower street fan, the McLeod RST twin disc clutch kit is an economically priced twin disc clutch kit. Able to handle 800hp, this clutch can handle almost any horse-power you can throw at it and still remain street-able. Organic lined clutch discs will provide smooth engagement with a soft pedal effort to make this clutch kit ideal for the street only performance enthusiast. This unit is not intended for competition use! Look to our RXT and RXT 1200 for those applications. This series of clutch comes in 3 different configurations to best suit your needs. Adapter ring version. Another McLeod Racing exclusive. We build a twin disc clutch using a Patented Approved adapter ring to bolt to your supplied flywheel. Complete Unit with Dedicated Flywheel. No need to search for the clutch as one number and the flywheel as another number. McLeod Racing has you covered with one part number and a complete dedicated unit ready to plug and play. You have the choice of running a Billet Steel flywheel for your street applications or a Billet Aluminum flywheel for your track cars.

Part TypeClutch Kit
BrandMCLEOD
Package Height3.1
Package Width14.0
Package Length14.7
Weight24.95 PG
Disc StyleFull face
Hardware IncludedYes
Number Of DiscsDouble
Pressure Plate StyleDiaphragm
Throwout Bearing IncludedNo
Clutch UsagePerformance
Spline Count26
Disc Diameter (In.)9.688 in.
Spline1 1/8" x 26
Flywheel IncludedNo
Pilot Bushing IncludedNo
Disc Diameter (Mm)246
Input Shaft Diameter1.125 in (28.575 mm)
Disc MaterialOrganic
Flywheel FitmentFor use with Ford Modular/GM LS-X
Alignment Tool IncludedYes
NotesCrank relief must be 6.250" or smaller for correct disc to flywheel contact. LS1/LS6 Flat Style Flywheels ONLY! Will NOT Work w/LS2/LS3/LS7 recessed flywheels. Ford Applications Aftermarket Transmission
Clutch Patterns11" GM LS-X With Dowel Pin; 11" Ford Modular with Dowel Pins
Clutch Disc Quantity2
Throwout Bearing StyleStandard
Hub StyleSolid
QuantitySold as a kit.
Mounting Hardware IncludedNo
Counterweight AssistNo
MakeGM, Ford, Pontiac
Horsepower Rating800
Input Shaft Diameter (In.)1.125 in.
Input Spline Quantity26 in (660.4 mm)
Disc Diameter9-11/16
Part FitmentDirect Fit
Vendor Part Number6912-07
Package Qty1
Package TypeEA
