Vehicle Info NeededMSD IGNITIONPART NUMBER: 121-8241
Blaster Replacement Coil 1995-98 Ford 4.6L DOHC/SOHC 4-Tower
$13595
3 left in stock
Ships Today
Lowest Price GuaranteeFord
- Blaster Replacement Coil
- 1995-98 Ford 4.6L DOHC/SOHC 4-Tower
- CARB E.O Number D-40-37
Coil Specs: - Turns ratio: 83:1
- Primary resistance: .53 OHMs
- Secondary resistance: 13.7K OHMs
- Inductance: 3.9 mH
- Maximum voltage: 40,000 Volts Features:
- Designed to be used with late model Ford waste spark ignition systems
- 83:1 turns ratio and lower primary resistance produce high voltage output
- Secondary towers designed for snap on spark plug terminals
- Primary terminals require Ford style connector
- 50-State Legal
- CARB E.O Number D-40-37
- Designed to be used with late model Ford waste spark ignition systems
- 83:1 turns ratio and lower primary resistance produce high voltage output
- Secondary towers designed for snap on spark plug terminals
- Primary terminals require Ford style connector
- CARB E.O. Approved
Reliable Factory Replacement Ignition Coils
MSD Blaster Series Coils work with a stock ignition or already MSD-equipped vehicles. These ignition coils directly bolt onto factory connections and provide an increased voltage output for improved performance.
Part TypeIgnition Coil
Product LineMSD Blaster Series Coils
BrandMSD IGNITION
Package Height3.7
Package Width4.4
Package Length5.4
Weight2.48 PG
Part CategoryPerformance Parts
Carb Eo NumberD-40-37 (pdf)
Primary Resistance0.530 ohms
Coil Wire AttachmentFemale/Socket
Coil StyleCoil pack
QuantitySold individually
Overall Length4.097 in (104.1 mm)
Ballast Resistor IncludedNo
Maximum Voltage40,000 V
Turns Ratio83:01:00
Coil ShapeSquare
Mounting Bracket IncludedNo
Inductance5.8 mH
Coil ColorRed
Coil Wire IncludedNo
Secondary Resistance12.8 ohms
Part FitmentDirect Fit
Coil Internal ConstructionEpoxy
Vendor Part Number8241
Package Qty1
Package TypeEA
