Lowest Price Guarantee- PCY Series high misalignment, two piece, black oxide coated rod end. Female mounting with a 1/2" bore and 1/2-20 left hand threads. Includes PTFE race lining.
- QA1 offers its 2-piece PCYF-T Chromoly Steel Series rod ends for applications requiring high misalignment. These black oxide coated rod ends offer superior load ratings over carbon steel two-piece rod ends and have a PTFE liner. The PCYF-T is an ideal choice for high misalignment applications with the highest misalignment available in the industry. Other sizes are available in the PCYF-T Series.`
Part TypeRod End
BrandQA1
Part CategoryPerformance Parts
Rod End AttachmentFemale Threads
Rod End FinishBlack oxide
Thread Length1.375 in (34.9 mm)
Rod End Head Bore Size0.5 in (12.7 mm)
Rod End Thread Size (In.)1/2-20 LH
QuantitySold individually
Rod End Centerline Length2.625 in (66.7 mm)
Jam Nut IncludedNo
Rod End Misalign Angle (Deg)65 degrees
Rod End Head Diameter1.5 in (38.1 mm)
Rod End Ball Width1.25 in (31.8 mm)
Grease FittingNo
Rod End Construction2-piece
Heat-TreatedYes
Rod End Head Width1.25 in (31.8 mm)
Rod End Static Load Capacity (Lbs.)15,038
Rod End MaterialSteel
Rod End StylePTFE lined
Part FitmentUniversal
Vendor Part NumberPCYFL8T
Package Qty1
Package TypeEA
