SONNAXPART NUMBER: 852-35280-02
Extreme-Duty Input Shaft GM TH400, 30-Spline Front Tooth, 300M High-Strength Steel
$52112
Items You Need
GM
Extreme-Duty Input ShaftGM TH400 35-Spline Front Tooth 1.125 in. Shaft Diameter 300M High-Strength Steel Sold Individually
35280-02 Features:
- Ideal for high-horsepower racing applications
- For use with aftermarket torque converters with internal turbine support
- Designed to be used with Sonnax Heavy-Duty Forward Drum 852-34554-01 or aftermarket drums with the compatible spline count
- The high-strength 300M steel is resistant to fracture
- 35-percent stronger than standard and 1 in. input shafts
Note:
- This shaft requires changing to a 35-spline turbine hub within the torque converter and the use of Pump Cover Big Shaft Stator Tube Kit 852-28154S-125 with a larger inner diameter
Upgrade Your Automatic Transmission for Maximum Strength!
Automatic transmission input shaft failure can be a common problem as power levels increase. Sonnax offers heavy and extreme-duty input shafts that are machined from specially heat-treated steel and utilize harder outer layers and ductile inner cores for strength and resistance. These shafts are suitable for any high-horsepower street, strip, or towing application.
Part TypeAutomatic Transmission Input Shaft
Product LineSonnax Heavy-Duty Input Shafts
BrandSONNAX
Package Height2.3
Package Width2.4
Package Length14.0
Weight2.8 PG
Part CategoryReplacement Parts
Input Spline Quantity35
Shaft Diameter1.125 in.
QuantitySold individually
Part FitmentSemi Universal
Input StyleGM TH400
Input Shaft Material300M
Vendor Part Number35280-02
Package Qty1
Package TypeEA
