Vehicle Info NeededT33-ALFY-04 6-Bolt Adapter Flange Yoke Kit, Fits Ford Mustang with 95mm bolt circle dia. pinion flange
Ships on 09/15/2026
Lowest Price Guarantee- 6-Bolt Adapter Flange Yoke Kit
- Fits Ford Mustang with 95mm bolt circle dia. pinion flange (automatic '05–'14/manual '05–'19).
- Fits Ford Mustang with 95mm bolt circle dia. pinion flange (automatic '05–'14
- manual '05–'19).
Sonnax T33-ALFY-04 Features:
Sonnax 6-bolt adapter flange yoke kit T33-ALFY-04 is an ideal upgrade for '05–'19 Ford Mustang driveshafts. Specifically designed to bolt up to 95mm bolt circle diameter pinion flanges, the Sonnax yoke allows elimination of the OE CV joint. When used with a stub and slip assembly, it makes it easy to also eliminate the rubber giubo (sometimes misspelled as guibo) or "flex" joint, converting a two-piece driveshaft into a one-piece, U-joint style driveline.
Combined with Sonnax tubing and weld yokes, this unique flange dramatically increases strength and durability while reducing future maintenance costs. This yoke is also very helpful when swapping a modern muscle car engine and transmission into an older street or hot rod, allowing the link to be made between the modern driveline and older chassis.
- Precision-machined for excellent fit and balance
- Helps eliminate the troublesome giubo and/or CV joint(s)
- Ideal for chassis swaps
- Flange yoke
- Bolts (6)
- Washers (6)
- U-Joint Series: 1330
- Pilot Type: M
- Material: 6061-T6 Aluminum
- Bolt Hole Diameter: 0.438"
- Flange Face to Centerline: 3.440"
- Weight: 1.830lbs
- Flange Outer Diameter: 4.720"
- Pilot Diameter: 4.457"
- Bolt Count: 6
- Bolt Circle Diameter: 95mm
Note: Sonnax flange yoke T33-ALFY-04 is a custom part and may fit more models than noted above. Measure flange O.D., output flange bolt holes and bolt circle diameter to determine if this yoke is appropriate for your build.
Contains:
Specs:
