Spohn Performance D09-1500-104-HCB Features:

This adjustable rear panhard track bar is our “high clearance” version and will provide an additional 1.00” of clearance between the inside edge of the panhard bar and the rear differential cover for those who are running aftermarket rear end covers that protrude out more than the factory rear cover. If you have the factory rear cover then use our SKU D09-1500-104 adjustable rear panhard track bar.

Replace the factory's weak and flexible rubber bushed rear panhard track bar on your 2009+ Dodge Ram 1500 4x2 or 4x4 with our heavy duty adjustable unit!

Our tubular adjustable rear panhard track bar allows for centering the rear end housing after lowering or lifting the ride height and provides for serious handling performance. It also allows for alignment of the rear end for clearance when running larger tires and greatly increases the rear end's lateral stability.

All ends are fitted with grease fittings for easy lubrication of the fluted polyurethane bushings.

Powder coated for a brilliant and durable finish.

• 1.00" x .095" wall DOM tubing
• Stronger, yet lighter than stock
• Polyurethane bushings (fluted) with grease fittings for easy lubrication
• Right hand and left hand threaded CNC machined 4140 chrome moly double male stud adjuster threads into 4130N chrome moly TIG welded threaded tube adapters
• This is the highest quality, easiest to adjust on the truck panhard bar on the market!
• Ships to you fully assembled and jig set at OEM length
• Provides an additional 1.00" of rear differential cover clearance to clear larger aftermarket rear end covers
• Powder coated for a brilliant and durable finish
• Mounting Hardware Included: No
• Adjustable: Yes
• Bushing Material: Polyurethane
• Bushing Color: Black
• Finish: Powder Coated
• Mounting Hole Diameter: 14
• End 1 Type: Bushing
• End 2 Type: Bushing
• Pre-Greased: Yes
• Grease Fitting Included: Yes
• Bushings Included: Yes
• Greaseable: Yes
• Additional Rear Cover Clearance: 1.000
• Bushing Durometer: 95
• Color: Gloss Black
• Compressed Length: 33.125
• Extended Length: 35.250
• Material: Mild Steel
• OEM Length: 33.625
