Oxygen SensorFits Select Buick, Chevy, GMC Applications Downstream, Upstream Position 4-Wire Narrow-Band Heated M18x1.5 Thread 325 mm (12.8 in.) Overall Length Male/Female Oblong Connector Sold Individually
This 4-wire narrow-band oxygen sensor fits select 2016-2026 Buick, Chevy and GMC applications and signals whether the exhaust is running rich or lean so the engine computer can trim fuel delivery. A built-in heater brings the element to operating temperature quickly after a cold start.
Walker Products 250-241188 Oxygen Sensor Features:
- Fits 2016-2022 Buick Encore, Chevy Spark; 2020-2024 Buick Encore GX; 2024 Buick Envista; 2016-2019 Chevy Cruze, Volt; 2016 Chevy Cruze NG; 2016-2024 Chevy Malibu
- Fits 2018-2021 Chevy Cavalier; 2018-2024 Chevy Equinox, GMC Terrain; 2018 Chevy Nuevo Aveo; 2019-2023 Chevy Aveo; 2021-2024 Chevy Trailblazer, Trax
- Also fits select Buick, Chevy and GMC applications
- Sensor locations by application: B1S1, B1S2 (bank and sensor number)
- Used in both upstream and downstream positions, depending on application
- 4-wire narrow-band oxygen sensor
- Built-in heater for fast warm-up
- M18x1.5 threaded mounting with a 22 mm hex, 325 mm (12.8 in.) overall length
- Male/female oblong connector at the harness end with 4 pin terminals
- Platinum electrode layer with a protective coating against combustion residue
Part TypeOxygen Sensor
BrandWALKER PRODUCTS
Package Height1.85
Package Width2.12
Package Length5.75
Weight0.21 PG
Part CategoryReplacement Parts
Wrench Size22
Universal Or Specific FitSpecific
Wire Quantity4
Wire Gauge Measurement20
Terminal TypePin
Connector GenderFemale
Overall Length12.8 in. (325mm)
Thread SizeM18 - 1.5
Mounting TypeThreaded
Connector ShapeOblong
Terminal GenderMale
Sensor TypeNarrow-Band
HeatedYes
Terminal Quantity4
Part FitmentDirect Fit
Vendor Part Number250-241188
Package Qty1
Package TypeEA
Some parts are not legal for use in California or other states with similar laws / regulations
