Oxygen Sensor2015-2019 Audi A3, Volkswagen Golf, Golf SportWagen, Golf Alltrack, GTI 5-Wire Wide-Band Heated M18x1.5 Thread 700 mm (27.6 in.) Overall Length Male/Female Oblong Connector Sold Individually
The oxygen sensor installs in the upstream position on select 2015-2019 Audi and Volkswagen applications. It measures the exhaust air-fuel ratio across a broad range so the engine computer can meter fuel precisely. A built-in heater brings the element to operating temperature quickly after a cold start.
Walker Products 250-25115 Oxygen Sensor Features:
- Fits 2015-2016 Audi A3; 2015-2018 Volkswagen Golf; 2015-2019 Volkswagen Golf SportWagen; 2017-2019 Volkswagen Golf Alltrack; 2019 Volkswagen GTI
- Engine coverage includes 1.8L I4, 2.0L I4 applications
- Sensor location by application: B1S1 (bank and sensor number)
- 5-wire wide-band oxygen sensor
- Built-in heater for fast warm-up
- M18x1.5 threaded mounting with a 22 mm hex, 700 mm (27.6 in.) overall length
- Male/female oblong connector at the harness end with 5 spade terminals
- Platinum electrode layer with a protective coating against combustion residue
Part TypeOxygen Sensor
BrandWALKER PRODUCTS
Package Height1.85
Package Width2.12
Package Length5.75
Weight0.35 PG
Part CategoryReplacement Parts
Wrench Size22
Universal Or Specific FitSpecific
Wire Quantity5
Wire Gauge Measurement20
Terminal TypeSpade
Connector GenderFemale
Overall Length27.56 in. (700mm)
Thread SizeM18 - 1.5
Mounting TypeThreaded
Connector ShapeOblong
Terminal GenderMale
Sensor TypeWide-Band
HeatedYes
Terminal Quantity5
Part FitmentDirect Fit
Vendor Part Number250-25115
Package Qty1
Package TypeEA
Some parts are not legal for use in California or other states with similar laws / regulations
