Oxygen Sensor2001-2006 Honda Insight, 2002-2004 Honda CR-V 4-Wire Narrow-Band Heated M18x1.5 Thread 280 mm (11 in.) Overall Length Female Square Connector Sold Individually
The oxygen sensor installs in the downstream position on 2001-2006 Honda Insight and 2002-2004 Honda CR-V. It signals whether the exhaust is running rich or lean so the engine computer can trim fuel delivery. A built-in heater brings the element to operating temperature quickly after a cold start.
Walker Products 350-34088 Oxygen Sensor Features:
- Fits 2001-2006 Honda Insight; 2002-2004 Honda CR-V
- Engine coverage includes 1.0L I3, 2.4L I4 applications
- Sensor locations by application: B1S2, B1S3 (bank and sensor number)
- 4-wire narrow-band oxygen sensor
- Built-in heater for fast warm-up
- M18x1.5 threaded mounting with a 22 mm hex, 280 mm (11 in.) overall length
- Female square connector at the harness end
- Platinum electrode layer with a protective coating against combustion residue
Part TypeOxygen Sensor
BrandWALKER PRODUCTS
Package Height1.85
Package Width2.12
Package Length5.75
Weight0.37 PG
Part CategoryReplacement Parts
Wrench Size22
Universal Or Specific FitSpecific
Wire Quantity4
Wire Gauge Measurement20
Terminal TypeSpade
Connector GenderFemale
Overall Length11.02 in. (280mm)
Thread SizeM18 - 1.5
Mounting TypeThreaded
Connector ShapeSquare
Terminal GenderFemale
Sensor TypeNarrow-Band
HeatedYes
Wiring Harness Length11.02 in. (280mm)
Part FitmentDirect Fit
Grade TypeStandard Replacement
Vendor Part Number350-34088
Package Qty1
Package TypeEA
Some parts are not legal for use in California or other states with similar laws / regulations
