Oxygen Sensor1996-1999 Saturn SC1, SC2, SL, SL1, SL2, SW1, SW2 1.9L I4 Engine 4-Wire Narrow-Band Heated M18x1.5 Thread 705 mm (27.8 in.) Overall Length Female Square Connector Sold Individually
The 4-wire narrow-band oxygen sensor is a replacement sensor for 1996-1999 Saturn SC1, SC2, SL, SL1, SL2, SW1 and SW2 with the 1.9L I4 engine in the downstream position. It signals whether the exhaust is running rich or lean so the engine computer can trim fuel delivery. A built-in heater brings the element to operating temperature quickly after a cold start.
Walker Products 350-34332 Oxygen Sensor Features:
- Fits 1996-1999 Saturn SC1, SC2, SL, SL1, SL2, SW1, SW2 with the 1.9L I4 engine
- Sensor location by application: B1S2 (bank and sensor number)
- 4-wire narrow-band oxygen sensor
- Built-in heater for fast warm-up
- M18x1.5 threaded mounting with a 22 mm hex, 705 mm (27.8 in.) overall length
- Female square connector at the harness end with 4 spade terminals
- Platinum electrode layer with a protective coating against combustion residue
Part TypeOxygen Sensor
BrandWALKER PRODUCTS
Package Height1.85
Package Width2.12
Package Length5.75
Weight0.31 PG
Part CategoryReplacement Parts
Wrench Size22
Universal Or Specific FitSpecific
Wire Quantity4
Wire Gauge Measurement20
Terminal TypeSpade
Connector GenderFemale
Overall Length27.76 in. (705mm)
Thread SizeM18 - 1.5
Mounting TypeThreaded
Connector ShapeSquare
Terminal GenderFemale
Sensor TypeNarrow-Band
HeatedYes
Wiring Harness Length705
Terminal Quantity4
Part FitmentDirect Fit
Grade TypeStandard Replacement
Vendor Part Number350-34332
Package Qty1
Package TypeEA
Some parts are not legal for use in California or other states with similar laws / regulations
