Vehicle Info NeededWILWOODPART NUMBER: 950-120-9689-LP
Dynapro Single Billet Caliper Piston Diameter: 1.75"
$15925
Ships on 09/08/2026
Lowest Price GuaranteeAnodized Black Single Caliper
- Dynapro Single Billet Caliper
- Piston Diameter: 1.75"
- Rotor Thickness: .19"
- Lug Spacing: 3.75"
- Anodized Black
- Wilwood's Dynapro Single Billet Caliper (DPS) represents the newest generation of calipers available as an upgrade or replacement for applications previously using the long-standing Dynalite Single (DLS) model series. DPS performance brake calipers combine superior strength with several new performance enhancements to make these the best "Dyna" series calipers ever built. The DPS is perfect for compact high performance braking as required in Open Wheel, Drag, Modified, Kart, Motorcycle and Off Road applications. The two piston caliper is rigid, lightweight and holds a .50" thick, 1.1 cubic inch brake pad. Internal fluid passage and multiple bleed fittings permit right or left, front or rear mounting options, with either 3.25" or 3.75" lug spacing, and will fit .25" to .38" thick rotors, with diameters from 6.00" to 13.00" High temperature square piston seals control piston retraction while the heavy wall stainless steel deep cup pistons reduce heat transfer from the pad to the brake fluid. Calipers accept 1/8''-27 NPT inlet fitting and come standard with Wilwood's exclusive Quick-E-Clip pad retainer.
The Dynapro Single Billet Caliper comes standard with Wilwood's black anodized coating, but is more spectacular in the brilliant polished version for a show car look. The machining versatility of Wilwood's CNC equipment sculpts a part that enhances wheel and suspension detail while maintaining the close tolerance design attributes of the Dynapro Single Series.
Part TypeDisc Brake Caliper
Product LineWilwood Dynapro Single Billet Calipers
BrandWILWOOD
Package Height3.5
Package Width4.5
Package Length5.8
Weight2.22 PG
Part CategoryPerformance Parts
Caliper Piston QuantityTwo
Caliper MaterialAluminum
Brake Pads IncludedNo
QuantitySold individually
Piston Diameter1.75 in (44.5 mm)
Fitting Attachment 1Female Threads
Rotor Thickness0.38 in (9.7 mm)
Caliper SeriesBillet DynaPro
Caliper LogoWilwood
Parking Brake ProvisionNo
Fittings IncludedNo
Brackets IncludedNo
Part FitmentSemi Universal
Caliper FinishBlack powdercoated
Vendor Part Number120-9689-LP
Package Qty1
Package TypeEA
