Wilwood 340-16399 Features:

Wilwood’s new Adjustable Reverse Mount Pedal Replacement Kit includes the Adjustable Brake pedal and balance bar assembly with the appropriate hardware to retrofit earlier design forged or cast pedal assemblies. Pedals feature an all-aluminum frame and forged aluminum pedal arms with ladder style construction. Pedal pads and pedal head are of special adjustable design that allows fine-tuning of the pedal location and clearance. Pedal head adjusts vertically to provide a 5.50, 5.88, or 6.25:1 ratio. Also Included with this assembly: trunnion, clevis hardware required in the conversion. 340-16399 kits will convert the following 5.1-6.25 to 1 ratio reverse mount assemblies: 340-11299,340-12509,340-13835,340-13836,340-13837,340-3342,340-4828, 340-5180,340-5181 and 340-6451.
