A clutch pedal joins two brake master cylinder mounts on an adjustable balance bar in this floor-mount assembly, letting a builder fine-tune both pedal ratio and front-to-rear brake bias from the same unit.

Adjustable Ratio Floor Mount Pedal Features:

• Pedal head adjusts vertically between 4.75, 5.25, or 5.75:1 ratio.
• Non-skid waffled pedal pads laterally adjust from 3.75 to 5.75 in. on center.
• Lightweight aluminum frame with reinforced I-beam style forged pedal arms.
• Balance bar detents every full turn, locks with the included jam nut, or accepts an optional remote adjuster knob.
• Accepts three Wilwood 2.25 in. vertical-mount flange single-outlet master cylinders, ordered separately.
