Edelbrock 2176PK - Edelbrock Performer Manifolds for Chrysler

Edelbrock 2176PK - Edelbrock Performer Manifolds for Chrysler

Edelbrock#350-2176PK

Performer Power Package
Intake Manifold, Carburetor and Camshaft Kit
  • SB-Chrysler 318-360ci
  • 4-bbl Spread-Bore Carb Flange (non-EGR)
  • Idle-5500 rpm
    • $745.99 Ships
    Easy Kits


    Edelbrock 2176PK - Edelbrock Performer Manifolds for Chrysler

    Edelbrock 2176PK - Edelbrock Performer Manifolds for Chrysler Details

    Chrysler 318-360ci Small Block V8

    Power Package includes matching:
    Performer Intake Manifold p/n 350-2176,
    Edelbrock Performer 600cfm Carburetor p/n 350-1406,
    Performer-Plus Hydraulic Flat Tappet Camshaft & Lifters p/n 350-2177.

    Designed for street 318-340-360ci Chrysler V8s. This intake manifold is a stock replacement/street legal part for 318-360ci V8s with OEM 4-bbl. carb.; 1966-72 (1973 non-CA); except stock equipped EGR. (Intake manifold p/n 350-3776 is a stock replacement/street legal part for same V8's with OEM 4-bbl carb; 1972-87.) This manifold is not for use on marine engines used in salt water. Will not fit 1992 and later Magnum engines.

    Installation Notes:

  • Port exit dimensions: .97'' x 1.95''
  • Manifold height: (A) 4.13'' , (B) 5.13''
    Click here to determine carburetor pad height.

    Carburetor Recommendations:
    OEM 4-bbl. carburetor

  • carb will work with non-EGR system
  • carb has provision for evaporative canister
  • carb requires automatic transmission rod extension kit p/n 350-8003 for 1/4'' rod or p/n 350-8004 for 5/16'' rod. Also use transmission kick-down linkage adapter kit p/n 350-8022 for 1977 vans
  • carb acceptable to factory cruise control

    Edelbrock Performer 600cfm Carburetor p/n 350-1405.

  • carb will work with non-EGR system
  • adapter for this carb supplied with manifold
  • carb has no provision for evaporative canister
  • Use stud, nut, and washer kit: JEGS 1-1/2'' stud kit p/n 555-15840 or JEGS 2'' stud kit p/n 555-15841
  • carb requires automatic transmission rod extension kit p/n 350-8003 for 1/4'' rod or p/n 350-8004 for 5/16'' rod. Also use transmission kick-down linkage adapter kit p/n 350-8022 for 1977 vans
  • carb acceptable to factory cruise control.
  • carb has manual choke only.
  • use throttle lever adapter p/n 350-1481 for 1966-later vehicles.

    Edelbrock Performer 600cfm Carburetor p/n 350-1406.

  • carb will work with non-EGR system
  • adapter for this carb supplied with manifold
  • carb has no provision for evaporative canister
  • carb requires automatic transmission rod extension kit p/n 350-8003 for 1/4'' rod or p/n 350-8004 for 5/16'' rod. Also use transmission kick-down linkage adapter kit p/n 350-8022 for 1977 vans
  • carb acceptable to factory cruise control.
  • use throttle lever adapter p/n 350-1481 for 1966-later vehicles.

    Edelbrock Thunder Series AVS 650cfm Carburetor p/n 350-1805.

  • carb will work with non-EGR system
  • adapter for this carb supplied with manifold
  • carb has no provision for evaporative canister
  • Use stud, nut, and washer kit: JEGS 1-1/2'' stud kit p/n 555-15840 or JEGS 2'' stud kit p/n 555-15841
  • carb requires automatic transmission rod extension kit p/n 350-8003 for 1/4'' rod or p/n 350-8004 for 5/16'' rod. Also use transmission kick-down linkage adapter kit p/n 350-8022 for 1977 vans
  • carb acceptable to factory cruise control.
  • carb has manual choke only.
  • use throttle lever adapter p/n 350-1481 for 1966-later vehicles.

    Edelbrock Thunder Series AVS 650cfm Carburetor p/n 350-1806

  • carb will work with non-EGR system
  • adapter for this carb supplied with manifold
  • carb has no provision for evaporative canister
  • carb requires automatic transmission rod extension kit p/n 350-8003 for 1/4'' rod or p/n 350-8004 for 5/16'' rod. Also use transmission kick-down linkage adapter kit p/n 350-8022 for 1977 vans
  • carb acceptable to factory cruise control.
  • use throttle lever adapter p/n 350-1481 for 1966-later vehicles.

    Camshaft Specs:
    Designed for optimum torque from the low-end to the mid-range. They are smooth idling cams for dailey drivers, trucks, vans, RVs and 4x4s. You can expect a major improvement in throttle response and torque.

    Note: Not for 1985 and later engines with roller lifters.
    Not legal for sale or use on pollution controlled vehicles.

    Duration Advertised:270° Intake / 270° Exhaust
    Duration @ .050'' Lift:204° Intake / 204° Exhaust
    Valve Lift:.420'' Intake / .420'' Exhaust
    Lobe Separation Angle:110°
    Open/Close @.050'' Cam Lift:Intake - 4° ATDC (opens) / 28° ABDC (closes)
    Exhaust - 36° BBDC (opens) / 12° BTDC (closes)

    • Edelbrock 2176PK - Edelbrock Performer Manifolds for Chrysler

    Idle-5500 RPM Power!

    Performer manifolds are dual-plane, low-rise intake manifolds with a 180° firing order and a patented runner design that delivers outstanding performance. This patented design greatly improves torque over a wide rpm range, especially off-idle through 5500 rpm. Provides crisp throttle response. Some Performer intakes are 50-state legal, when used with the correct carburetor and in the correct application.

    Accessories
    - Items You May Need
    Grime Boss A541S30X - Grime Boss Hand Wipes
    Grime Boss A541S30X - Grime Boss Hand Wipes
    Only $5.99
    Ships
    Grime Boss A544R10X - Grime Boss Hand Wipes
    Grime Boss A544R10X - Grime Boss Hand Wipes
    Only $2.99
    Ships
    Grime Boss M956S8X - Grime Boss Hand Wipes
    Grime Boss M956S8X - Grime Boss Hand Wipes
    Only $8.99
    Ships
    Note:To insure proper manifold to cylinder head sealing, Edelbrock recommends using an embossed intake gasket like Fel-Pro's Printoseal or Mr.Gasket's Ultra Seal. Fel-Pro's Perma Torque Blue and other similar gaskets do not compress well when used with an aluminum intake manifold and may cause vacuum leaks.
