5M8088H-STD Race Main Bearing Set, Standard Size, Toyota 1UZ-FE 3969cc V8 DOHC 4v
InfoVehicle Info Needed
ACL BEARINGSPART NUMBER: 654-5M8088H-STD

5M8088H-STD Race Main Bearing Set, Standard Size, Toyota 1UZ-FE 3969cc V8 DOHC 4v

$16907
ShippingShips on 11/24/2026
Lowest PriceLowest Price Guarantee

Items You Need

Engine Assembly Lube [4 oz. Bottle]

JEGS

Engine Assembly Lube [4 oz. Bottle]

Part Number : 555-28000
$599$6.99
You Save$1.00
Plastigauge Kit

JEGS

Plastigauge Kit

Part Number : 555-80593
$1499$16.99
You Save$2.00
Ultra-Torque Assembly Lube w/Brush Top Container 20 ounces

ARP

Ultra-Torque Assembly Lube w/Brush Top Container 20 ounces

Part Number : 070-100-9911
$3799
Break-In/Engine Oil Supplement [12 oz. Bottle]

JEGS

Break-In/Engine Oil Supplement [12 oz. Bottle]

Part Number : 555-28060
$1009$11.99
You Save$1.90

Toyota
Race Main Bearing Set
  • Standard Size
  • Toyota 1UZ-FE 3969cc V8 DOHC 4v
  • Set of 5

    ACL Bearings 5M8088H-STD Features:

    Trusted by champions worldwide, ACL RACE Series Bearings are the choice for record-setting engines from sport compact to small block race machines. Engineered w/a unique blend of design, metallurgy, and precision manufacturing, these Bearings deliver unmatched durability and performance under extreme conditions.

    • Width: 0.886 in.
    • Outside Diameter: 2.8352 in.
    • Outside Diameter: 2.8346 in.
    • Shaft Diameter: 2.6378 in.
    • Shaft Diameter: 2.6373 in.
    • Grade Type: Performance
    • Maximum Wall Thickness: 0.0981 in.
    • Unleash Unmatched RPM Performance with ACL Race-Series Main Bearings

      ACL Race-Series Main Bearings bring race-tested durability, precision engineering, and state-of-the-art metallurgy into your high-performance build. Their trimetal design features a high-strength overlay plate with reduced thickness for improved fatigue resistance, backed by hardened steel for enhanced support and retention under extreme conditions. These bearings deliver when the going gets tough—on the street, the strip, or the racetrack. Available for various domestic and international applications.

      ACL also offers versions with extra oil clearance (HX) or coated (HC).

    Part TypeMain Bearing
    Product LineACL Bearing Race-Series Main Bearings
    BrandACL BEARINGS
    Package Height1.38
    Package Width3.58
    Package Length6.3
    Weight0.99 PG
    Part CategoryPerformance Parts
    Maximum Wall Thickness0.0981 in.
    Shaft Diameter2.6378 in.
    Part FitmentDirect Fit
    Outside Diameter2.8352 in.
    Product Width0.886 in.
    Grade TypePerformance
    Vendor Part Number5M8088H-STD
    Package Qty1
    Package TypeEA
