Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Endurance Series Batteries
- Endurance Series Battery
- BCI Group 49
- 58 lbs
- 13.9" L x 6.8" W x 7.5" H
- Cold Cranking Amps: 1115
- Cranking Amps: 1846
- Right Side Positive
PERFORMANCE
Voltage: 12 volts
Full Charge Voltage: 13.8 volts
Short Circuit Current: 4000 - Estimated
Cranking Amps 30 sec @ 80F: 1846
Cranking Amps 30 sec @ 32F: 1520
Cold Cranking Amps 30 sec @ 0F: 1115
Reserve Capacity: more than 150 min
Capacity (C/20 rate): 100 amp hr
Life Cycle @ 10% DOD: Up to 3000-3500 cycles
PLEASE NOTE: ALL RATINGS ARE TESTED AND CONFIRMED PRIOR TO SHIPMENT USING A MIDTONICS 400XL BATTERY TESTER
PHYSICAL SPECS
Unique Features: Durable Virgin Poly Casing, Horizontal & Vertical Mounting
BCI Group: Group 49
Length: 13.9'
Width: 6.8'
Height: 7.5'
Minimum Weight (lbs): 58 lbs
Post Type: SAE Automotive Posts
Recommended Mounts: OEM Group 49 Mounts
High-Performance Batteries for Maximum Power
Braille Endurance Series Batteries are OE replacement-style batteries that feature the highest cranking power and the longest run times (Amp/Hr Ratings) in their class. They offer the AGM internal racing technology developed for Braille's Advance AGM and Carbon Fiber Batteries!
Note: AGM (Absorbed Glass Mat) batteries are fully charged, ready to install, and compatible with a vehicle's charging system. If additional charging is ever needed, an AGM-compatible charger will be required.
Part TypeBattery
Product LineBraille Endurance Series Batteries
BrandBRAILLE BATTERY
Package Height8.9
Package Width14.3
Package Length14.3
Weight59.78 PG
Weight58 lb (26.304 kg)
Part CategoryPerformance Parts
Cranking Amps At 32 Degrees F1,520 amps
Reserve Capacity150
QuantitySold individually
Overall Length13.9 in (353.1 mm)
Bci Group Number49
Battery TypeAGM
Cranking Amps At 0 Degrees F1,115 amps
Battery UsageStarting
Battery TerminalsTop
Part FitmentUniversal
Volts12 volts
Vendor Part NumberB10049
Package Qty1
Package TypeEA
