This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
- 1987-1995 Small Block Chevy TBI 305/350ci
- OE Throttle Body Injection Flange (EGR)
- Idle-5500 RPM Range
- Polished Finish
Designed for 1987-95 305/350ci (5.0/5.7L) Chevy Throttle Body Injectioned (T.B.I.) engines. Ideal for trucks, Blazers and Suburbans (Will not fit Caprice or Buick and Cadillac "B" Bodies). For 305 and 350 V8s with OEM T.B.I. 1987-95. T.B.I. water jacket similar to stock. Accepts all OEM equipment and small-bore (1-11/16') throttle body injectors only. No chip changes or computer mods required unless entire 5.7L Power Package (manifold, cam, heads) is used. Computer chip is supplied free of charge with proof of purchase of manifold, cam and heads. The chip re-programs your computer for optimum power gains when the entire package is installed. This Total Power Package greatly improves performance.
Installation Notes: - Port exit dimensions: 1.13" x 1.87"
- Manifold height: (A) 3.70' , (B) 5.10' - .250' taller than stock
- Pad Height: 4.40" Click here to determine throttle body pad height.
- Use stock Throttle Body Injection unit.
- Requires gasket #809-10159409 or Fel-Pro #375-MS93317
