14-Circuit Universal Fuse Block
Universal Fuse Block
  • 14-Circuit
  • Master On/Off Switch
  • 7 in. x 5 11/16 (.688) in.
  • Includes:
    • (12) ATC Fuses
    • (1) Pre-Wired Flasher
    • (1) Pre-Wired Hazard
    • (1) Pre-Wired Horn Relay
    • (1) Aluminum Fuse Cover & Mounting Bracket

      Features

      • Each circuit utilizes factory GM wiring codes & colors
      • The compact design makes it easy to relocate or hide
      • Each connection is crimped and soldered by hand
      • Fuse box is mounted to a brushed aluminum mounting bracket

      Supported Circuits:

      • Stop / Radio Constant
      • Horn Headlights
      • Dome / Hazard
      • Fuel Pump
      • Radio / Ignition
      • Gauges Coil
      • Electric Fan
      • Wiper / Back-Up
      • A/C & Heat
      • Turn Signal
    • Quality Wiring Harnesses at Affordable Prices

      JEGS Universal Wiring Harnesses fit almost any car or truck with a front-mounted engine and fuse block located under the dash near the steering column. These wiring harnesses are available in 14-Circuit and 20-Circuit models and require limited space under the dash for mounting. Our kits use premium quality high-temperature GXL coated copper stranded wire for reliability.

      Show More

      GXL wire has a temperature rating of -59 degree F (-51 degree C) to 257 degree F (125 degree C) and is resistant to moisture, grease, oil, gasoline, most acids and solvents. Each wire is color-coded and labeled for easy identification during installation and to simplify even further all wires are attached to the fuse block. Every attached terminal is machine crimped and hand-soldered making the best connections possible. Each fuse block includes a horn relay, turn signal relay, hazard flasher and standard ATO fuses. Wiring harnesses will work with a dash mounted or steering column mounted ignition switch and also have optional connectors for common GM-style accessories, such as dimmer switch, hazards, and alternator. For vehicles that don't use GM accessories, simply omit the extra connectors during installation. The installation instructions show how to make all connections for GM, Ford, and Chrysler vehicles.

    Part TypeFuse Block
    Product LineJEGS Universal Wiring Harnesses
    BrandJEGS
    Package Height7.9
    Package Width9.1
    Package Length9.5
    Weight2.15 PG
    Part CategoryPerformance Parts
    Wiring Harness IncludedNo
    Universal Or Specific FitUniversal
    Quantity1
    Horn Relay IncludedYes
    Fuse StyleATO/ATC
    Total Circuit Quantity14
    Mounting Bracket IncludedYes
    Body MaterialPlastic
    Fuse Assembly IncludedYes
    Flashers IncludedYes
    Voltage12 v
    Part FitmentUniversal
    Fuses IncludedYes
    Package Qty1
    Package TypeEA
