Seal Types:

• FKM Fluorocarbon for Oil, Water, Transmission Fluid, Pump Gas, Race Gas, E85 and Diesel applications Click here for Non-Valved FKM Fittings
• EPDM seals for Methanol (Methyl Alcohol), Ethanol (Ethyl Alcohol) and Nitromethane applications Features:
• 100% Leak Tested
• Replaces Any Fitting in Any Location
• Available for virtually all Fuel, Oil, and Water Applications
• Will not wear out
• Avoids stripping, cross-threading, and over-tightening
• Any 5000 series plug will work with any 5000 series socket
• Maximum Operating Pressure: 200 psi
• Operating Temperature: -40° to 350° F; -40° to 177° C
• Works with most steel-braided, lightweight black, and push-to-lock hose styles except PTFE
• Jiffy-tite fittings permit fluid to flow in both directions



  Notes:
• Fittings should not be used on brake lines.
• Push Lock Hose End Fittings uses "Push Loc" Style Hose
• Hose Barb fittings uses standard braided hose but requires a clamp or crimp collar Fitting Selection Guide
