New Vintage USA 77011-01 Features:

NVU kits for late C3 Corvette (78-82) upgrade not only the function but the style of the dash as well. Choose from several Bold graphic packages to bring your interior into the 21st century! Kits are installed in the factory location using NVU's exclusive mounting brackets. Console gauges fit in stock location behind the bezel and an extra filler gauge is included for the 5th opening. need to add on? No problem, just select a matching series gauge and monitor virtually everything. All NVU kits operate on any old school small or big block, modern LS or LT engine and transmissions.
Performance II Series instruments have the combined style of European sports car and racing gauges. This performance look has a classic gauge feel without the "in-your-face" look of a racing gauge. Full sweep stepper motors for higher dial resolution and blue LED back lighting at night. Stainless or bezels and flat glass add to the high class, OE installed look. Just like always, NVU does not have any logos on the dial so the final result will be a professional, custom look.
Looks are only skin deep; all Performance II instruments are based on our Phoenix platform with user select able inputs, OLED screens, stepper motor technology all made in the USA. All 6-gauge kits with OLED screens feature Phoenix Direct Drive technology, by far the easiest way to wire up a 6-gauge kit.
C3 (late) Speedometer and tachometer mounting bracket.
C3 Console mounting bracket
C3 console block out pieces
Speedometer 4-3/8"
Tachometer 4-3/8"
Fuel gauge 2-1/16" (0-90 Ω)
Water Temperature gauge 2-1/16"
Oil pressure gauge 2-1/16"
Voltmeter 2-1/16"
Direct drive extension harnesses
Oil pressure sender
Temperature sender
Bushing kit
Programming buttons
AMP harnesses
Back clamps
Gauge mounting hardware
** Speed sender may be required--not included please check your application

• Speedometer Gauge Included: Yes
• Tachometer Gauge Included: Yes
• Water Temperature Gauge Included: Yes
• Oil Pressure Gauge Included: Yes
• Voltage Gauge Included: Yes
• Fuel Gauge Range: Yes
• Fuel Sender Included: Yes
• Bezel Included: No
• Bracket Included: Yes
• Speed Sender Included: No
• Temperature Sender Included: Yes
• Oil Pressure Sender Included: Yes
• Wiring Harness Included: Yes
• Indicator Lamps: Yes
• Gauge Style: Analog
• Gauge Dial Color: Black
• Gauge Number Color: White
• Gauge Pointer Color: Red
• Bezel Finish: Stainless
• Gauge Lens: Flat Glass
